Zenith 40 Series Exposed Frame Curtain Wall
Zenith 40 Series Exposed Frame Curtain Wall - Aluminum Curtain Wall Manufacturer - Zenith 40 Series Exposed Frame Curtain Wall
Product Overview
Product Overview
Zenith 40 Series Exposed Frame Curtain Wall – Premium architectural curtain wall system.
Technical Specifications
| Thermal Break Strip | Non-thermal break system |
| Profile Thickness | 40mm |
| Frame Visible Face | – |
| Mullion Visible Face | Outdoor: 40mm; Indoor: 40mm |
| Sash Visible Face | – |
| Glass Configuration (Frame & Sash) | 6mm Clear Glass + 12mm Argon Gas Spacer + 6mm Clear Glass |
| Hardware Brand | – |
| Insect Screen System & Mesh Type | – |
| Available Colors | Sand Gray, Sand Brown, Starry Gray, Star Coffee |
| Application Scenario | Villa Lobby / High-end Residential Spaces |
| Notes | – |
Technical Specifications
Features & Benefits
Thermal Efficiency
Multi-chamber thermal break design reduces heat transfer, achieving U-factors as low as 0.24 W/m²K.
Acoustic Performance
Superior sound insulation with STC ratings up to 48 dB for noise-sensitive environments.
Modular Design
Factory-assembled unitized system reduces on-site installation time by up to 40%.
Weather Resistance
Pressure-equalized drainage system with multi-stage gaskets ensures water-tight performance.
Fire Safety
Integrated fire-stop barriers and non-combustible materials meet international fire codes.
Easy Maintenance
Removable glazing stops and accessible gaskets simplify replacement and maintenance.
Typical Applications
Commercial High-Rise
Unitized curtain wall for buildings over 20 stories.
Corporate Headquarters
Custom architectural facades for landmark offices.
Hospitality & Hotels
Premium glazing for 5-star hotel developments.
